Below are the lists of parts for the Gibson EB-0 bass, with part numbers and some limited description as recommended in three specific documents, as published by Gibson in 1965, 1971 and 1977. All three lists are just that: a list of components; a snapshot of a 'possible' EB-0. In actual fact, the components of all Gibson instruments were so fluid that there are plenty that do not fit exactly. And there are parts required for certain incarnations of the EB-0 that are not included in any of these lists at all. The 1971 and 1977 lists do suggest parts for what the call 'old-style' EB-0s; but in fact these are typically just lists of newer parts that are currently available and should work.
Further information on specific Gibson bass parts.
January 1965 |
| Bridge | BR-655N | Nickel |
| Fingerboard | F-655 | Rosewood, pearloid dot inlay, unbound, 30 1/2" scale 20 frets |
| Fingerrest | FR-660N | Celluloid, comp. bl/w/bl |
| Handrest | HR-655N | Nickel |
| Machine heads | MH-538 | "Elephant ears" individual pegs |
| Truss rod cover | TRC-20-N | Celluloid, black, white edge |
| Pickup & control assembly (Complete) | CPA-660 | |
| Control assembly (Complete) | CA-660-1 | |
|
| Pickup | PU-601-N | With nickel cover |
| Coil only | PUC-601 | |
| Cover only | UC-655N | |
|
| Control pot (volume and tone) | CBA-811-1053 | |
| Knob - volume | K-2BL-2A V | |
| Knob - tone | K-2BL-2A T | |
| Jack | J-11 | |
|
1971 |
| Bridge | 80035 | Tune-O-matic assembly |
| Anchor | 10904 | |
| Stud | 10937 | |
| Hex screw | 10556 | |
| Saddle screw | 10561 | |
| Delrin insert (saddle) | 10514 - treble side 10515 - bass side | |
|
| Machine heads | 82536 14548 - treble side 14547 - bass side | Kluson 538, chrome - complete assembly |
| Machine heads (split headstock) | 82535 14747 - treble side 14746 - bass side | Schaller M-4-C - complete assembly |
| Machine heads | 82534 14572 - treble side 14571 - bass side | Schaller M-4 - complete assembly |
|
| Fingerrest | 82025/12383 | Complete assembly/fingerrest only |
| Handrest | 80037/19410 | Chrome - complete assembly/handrest only |
| Truss rod cover (EB0) | 80533/19093 | Scripted - complete assembly/cover only |
| Truss rod cover (EB0L) | 80534/19085 | Scripted - complete assembly/cover only |
| Pickup & control assembly (Complete) | 81024 | |
| Control assembly (Complete) | 13781 | |
|
| Pickup | 13559 | With cover and mounting ring |
| Coil only | 13517 | |
| Cover only | 13912 | |
|
| Control pot - volume | 70027 | 1 required |
| Control pot - tone | 70021 | 1 required |
| Knob - volume | 19232 | |
| Knob - tone | 19231 | |
| Dial pointers | 15758 | |
| 3/8-32 hex nut | 15401 | Nickel plated |
| 3/8" flat washer | 15755 | Nickel plated |
|
| Molded 4 string bass nut - notched | 29008 | |
|
1977
Parts unlisted are as above |
| Bridge | 80053 | Tune-O-matic assembly, three point bridge |
| Stud | 10557 | 2 required |
| Stud | 10912 | 1 required |
| Anchor | 10904 | |
| Metal inserts | 10380 - 1st string 10381 - 2nd string 10382 - 3rd string 10383 - 4th string
| |
|
| Machine heads | 82510 14576 - treble side 14575 - bass side | Schaller M4-S (complete assembly with screws) |
|
| Fingerrest | 82025/12470 | Complete assembly/fingerrest only (b/w/b/w/b) |
| Truss rod cover | 80516/19012 | Plain - complete assembly/cover only |
| Switch, rotary | 70468 | 4 position |
| Choke | 19501 | |
|
